This camera offers exceptional image quality with a 30.4MP full-frame sensor and DIGIC 6+ processor, ensuring detailed, low-noise photos even in low light. It excels in both photography and 4K video, allowing for 8.8MP still grabs. The 61-point AF system ensures fast, precise focus, while the touchscreen facilitates easy control. Built-in Wi-Fi, NFC, and GPS enhance connectivity and convenience, making it a versatile tool for capturing high-quality images and videos in various conditions.
Features
- 30.4MP Full-Frame CMOS Sensor
- DIGIC 6+ Image Processor
- 3.2" 1.62m-Dot Touchscreen LCD Monitor
- DCI 4K Video at 30 fps; 8.8MP Still Grab
- 61-Point High Density Reticular AF
- Native ISO 32000, Expanded to ISO 102400
- Dual Pixel RAW; AF Area Select Button
- Dual Pixel CMOS AF and Movie Servo AF
- 7 fps Shooting; CF & SD Card Slots
- Built-In GPS and Wi-Fi with NFC
Canon 5D Mark IV DSLR Overview
Continuing on in their legacy of powerful workhorse cameras, Canon has released the 5D Mark IV DSLR which is an outstanding still photography option and an able 4K-capable video machine. This multimedia maven offers a newly developed 30.4MP full-frame CMOS sensor paired with the DIGIC 6+ image processor in order to balance fine detail and resolution with low-light performance and sensitivity. It is able to work within a native range of ISO 100-32000, which can then be expanded to an impressive ISO 50-102400, for sharp, low-noise images in a variety of conditions. Along with these improvements to image quality, users will enjoy a performance boost across the board with an enhanced AF system, built-in Wi-Fi, NFC, and GPS, and much more.
Performance and Autofocus
In order to deliver detailed images quickly and effectively the 5D Mark IV leverages the power of the DIGIC 6+ image processor, which can handle up to 7 frames per second during continuous shooting. It also uses a 150,000-pixel RGB+IR metering sensor to evaluate the scene and subjects for accurate exposures under a variety of different lighting conditions. An improved 61-point High Density Reticular AF furthers the camera's speed by tracking and locking onto subjects quickly and accurately for tack sharp photos. A new AF area select button is now available as well for near immediate access to this setting.
Video Capabilities
Video benefits from the addition of Dual Pixel CMOS AF and Movie Servo AF to smoothly rack focus during a shot. Shooters can even make use of the 3.2" 1.62m-dot touchscreen LCD to simply tap to adjust the focus point. Furthermore, now that the camera has DCI 4K (4096 x 2160) video recording at up to 30 fps, users can snag 8.8MP stills from the video for an even faster capture option. Tied into the Dual Pixel sensor architecture is a brand new feature for Canon: Dual Pixel RAW, which allows for fine tuning of certain image parameters, including bokeh shift and focus micro adjustment, after the image is taken.
Specifications
Imaging
- Imaging
- Lens Mount
- Canon EF
- Camera Format
- Full-Frame (1.0x Crop Factor)
- Pixels
- Actual: 31.7 Megapixel
Effective: 30.4 Megapixel
- Max Resolution
- 30.4 MP: 6720 x 4480
- Aspect Ratio
- 3:2
- Sensor Type / Size
- CMOS, 36 x 24 mm
- File Formats
- Still Images: JPEG, RAW
Movies: MJPEG, MOV, MP4, MPEG-4 AVC/H.264
Audio: AAC, Linear PCM (Stereo)
- Bit Depth
- 14-bit
- Dust Reduction System
- Yes
- Memory Card Type
- CompactFlash
SDXC
SDHC
SD
Focus Control
- Focus Control
- Focus Type
- Auto & Manual
- Focus Mode
- Continuous-servo AF (C), Manual Focus (M), Single-servo AF (S)
- Autofocus Points
- Phase Detection: 61, 41 cross-type
Viewfinder/Display
- Viewfinder/Display
- Viewfinder Type
- Pentaprism
- Viewfinder Eye Point
- 21.00 mm
- Viewfinder Coverage
- 100%
- Viewfinder Magnification
- Approx. 0.71x
- Diopter Adjustment
- - 3 to +1 m
- Display Screen
- 3.2" Rear Touchscreen LCD (1,620,000)
- Screen Coverage
- 100%
- Diagonal Angle of View
- 170.0°
Exposure Control
- Exposure Control
- ISO Sensitivity
- Auto, 100-32000 (Extended Mode: 50-102400)
- Shutter
- Type: Electronic & Mechanical
Speed: 30 - 1/8000 second, Bulb Mode
- Remote Control
- TC-80N3, RS-80N3 (Optional)
- Mirror Lock-Up
- Yes
- Metering Method
- Evaluative metering, Partial Metering, Spot metering
- Exposure Modes
- Modes: Aperture Priority, Auto, Manual, Programmed Auto, Shutter Priority
Metering Range: EV 0.0 - EV 20.0
Compensation: -5 EV to +5 EV (in 1/3 EV steps)
- Continuous Shooting
- Up to 7 fps at 30 MP for up to 21 frames in raw format
Up to 7 fps at 30 MP for unlimited frames in JPEG format
- White Balance Modes
- Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten
Flash
- Flash
- Built-in Flash
- No
- Max Sync Speed
- Mechanical Shutter: 1 / 200 seconds
- Flash Compensation
- -3 EV to +3 EV (in 1/3 or 1/2 EV steps)
- Dedicated Flash System
- eTTL
- External Flash Connection
- Hot Shoe, PC Terminal
AV Recording
- AV Recording
- Video Recording
- Yes, NTSC/PAL
- File Size
- 4096 x 2160p
1920 x 1080p
1280 x 720p
- Video Format
- 4K
M-JPEG
4096 x 2160p / 29.97 fps (500 Mbps) / 24 fps (500 Mbps) / 23.98 fps (500 Mbps)
High Definition
MOV
1920 x 1080p / 59.94 fps (180 Mbps) / 29.97 fps (90 Mbps) / 24 fps (90 Mbps)
/ 23.98 fps (90 Mbps) / 59.94 fps (60 Mbps) / 29.97 fps (30 Mbps)
/ 24 fps (30 Mbps) / 23.98 fps (30 Mbps)
1280 x 720p / 120 fps (160 Mbps)
High Definition
MP4
1920 x 1080p / 59.94 fps (60 Mbps) / 29.97 fps (30 Mbps) / 24 fps (30 Mbps)
/ 23.98 fps (30 Mbps) / 29.97 fps (12 Mbps)
- Exposure Control
- Auto: Shutter Speed, Aperture, ISO
Manual: Shutter Speed, Aperture, ISO
- ISO Sensitivity
- Auto, 100 - 32000
- Exposure Compensation
- -3 EV to +3 EV (in 1/3 or 1/2 EV steps)
- Focus
- Auto
Manual
Continuous Auto
- Video Clip Length
- 4096 x 2160
29 min. 59 seconds
- Audio Recording
- Built-in Mic: With Video, Mono
Optional External Mic: With Video, Stereo
Performance
- Performance
- Start-up Time
- 0.1 seconds
- Shutter Lag
- 0.058 seconds
- Self Timer
- 10 seconds, 2 seconds
- Interval Recording
- Yes
- Connectivity
- 1/8" Headphone, 1/8" Microphone, Canon N3, HDMI C (Mini), USB 3.0
- Wi-Fi Capable
- Yes
Power
- Power
- Battery
- 1x LP-E6N Rechargeable Lithium-ion Battery Pack, 7.2 VDC, 1865 mAh
- AC Power Adapter
- ACK-E6 (Optional)
- Operating/Storage Temperature
- Operating
32 to 104°F (0 to 40°C)
Humidity: 0 - 85%
Physical
- Physical
- Dimensions (WxHxD)
- 5.9 x 4.6 x 3.0" / 150.7 x 116.4 x 75.9 mm
- Weight
- 1.76 lb / 800 g body only
