DJI SDR Transmission Combo 2

SKU: 1026871     MPN:

190021173736

$1,239.00

$1,077.39 excl. GST

in stock In Stock
Price On Application Pre-order now! in stock In Stock In our warehouse Available for home delivery Out of stock
For more information about availability, please:

This compact and lightweight system offers professional wireless video transmission with improved interference resistance and higher image quality. It supports DCI 4K/60fps 10-bit HDR transmission, making it ideal for both small and large productions. With a range of up to 4 km and low latency, it ensures a responsive feed. The flexible design allows easy switching between transmitter and receiver roles, and it integrates seamlessly with handheld rigs and DJI stabilisers for versatile use on set.

Features

The DJI SDR Transmission 2 Combo

The DJI SDR Transmission 2 Combo brings professional wireless video transmission to productions of all sizes, combining improved interference resistance, higher image quality and extended transmission range in a compact, lightweight system. Its flexible transceiver design allows each unit to switch between transmitter and receiver roles, making it easy to adapt the setup as production requirements change.

Designed for various productions

Designed for everything from compact camera setups to complex multi-camera productions, DJI SDR Transmission 2 supports DCI 4K/60fps 10-bit HDR transmission with H.265 encoding at up to 50 Mbps. Transmission range reaches up to 4 km, while latency can be as low as 35 ms, providing a responsive feed for monitoring, focus adjustment and remote operation.

A single transmitter can feed up to eight receivers with remote control, while multi-group operation supports up to five transmitters and 40 receivers simultaneously. Auto Channel 2.0 intelligently coordinates frequencies and responds to changing interference, helping maintain a stable connection on busy sets.

  • At approximately 136 g per transceiver, the system is easy to integrate with handheld rigs and DJI RS series stabilisers.
  • It also works with the DJI Ronin app for monitoring and camera control, with professional tools including LUTs, histogram, waveform and false colour.
  • Power options include NP-F batteries, USB-C PD power and direct power from compatible DJI stabilisers.

Specifications

Key Features

DCI 4K/60fps 10-bit HDR wireless video transmission
Up to 4 km transmission range
Latency
as low as 35 ms
Maximum encoding bitrate
up to 50 Mbps
1 transmitter to up to 8 receivers with control
Multi-group operation
up to 5 transmitters and 40 receivers
Auto Channel 2.0 intelligent frequency coordination
TX/RX switchable transceiver design
Pairing-free camera feed switching
DJI Ronin app monitoring and control
Monitoring tools
LUT, histogram, waveform and false colour
PTP and compatible Sony CEC camera control
Compatible with selected DJI RS series stabilisers, Ronin 2 and Master Wheels
Power options
NP-F battery, USB-C PD and compatible DJI gimbal
Weight
Approx. 136 g per transceiver
