DJI Mic 3 Camera-Mount Wireless Receiver
Features
Part of DJI's Mic 3 wireless system, the Camera-Mount Wireless Receiver is a compact, 2-channel receiver available individually to expand your existing setup or serve as a backup. It supports stereo and mono audio channels and can be paired with up to four Mic 3 transmitters and seven additional receivers for multi-person audio capture across a variety of production environments. The receiver features support for both timecode input and output for improved postproduction workflows.
A 3.5mm TRS output allows direct audio recording to your camera, while a dedicated 3.5mm headphone jack provides real-time monitoring. An included USB-C adapter allows you to plug it directly into your mobile device. Purchase the separately available Mic Series Camera Adapter for direct compatibility with Sony MI shoes. Dual-band wireless and Bluetooth 5.4 technology ensure communication from up to 1312' away. An AMOLED touchscreen and onboard controls let you adjust parameters directly from the receiver. Further control is available via the DJI Mimo mobile app. The built-in rechargeable battery delivers up to 10-hour runtime.
Additional Details
4-channel receiver pairs with up to four DJI Mic 3 transmitters and seven additional receivers
Dual-band wireless support, Bluetooth 5.4
Mounts on camera with built-in shoe adapter
3.5mm TRS audio output to camera, 3.5mm headphone jack
USB-C charging port, USB-C audio adapter
Separately available Camera Adapter connects receiver directly to MI shoes
Timecode I/O support
AMOLED touchscreen, onboard controls
Rechargeable battery with 10-hour runtime
Specifications
System
- Wireless Technology
- Digital 2.4 GHz / Digital 5.8 GHz / Bluetooth
- Diversity
- Non-Diversity
- RF Frequency Band
- 2400 to 24,835 MHz / 5150 to 5850 MHz
- Max Operating Range
- 400 m (Line of Sight)
80 m (with Obstruction) - Max Transmitters per Band
- 4
- Built-In Recorder
- No
- Timecode Support
- Yes
- Mobile App Compatible
- Yes: Android & iOS
- App Name
- DJI Mimo
Receiver
- Receiver Type
- 1x Camera-Mount
- Mounting Options
- Shoe-Mount (with Included Hardware)
USB-C Plug-In (with Included Adapter) - Antenna
- 1x Internal
- Number of Audio Channels
- 2
- Audio I/O
- 1x 1/8" / 3.5 mm TRS Unbalanced Output
1x 1/8" / 3.5 mm TRS Headphone Output - Network I/O
- No
- USB/Lightning Connectivity
- 1x USB-C Female
- Frequency Response
- 20 Hz to 24 kHz
- Display
- OLED
Power Requirements
- Battery
- Receiver Battery Type
- 1x Built-In Rechargeable - 275 mAh
- Receiver Battery Life
- 10 Hours
- Battery Charging Time
- 50 Minutes
- AC/DC Power Adapter
- No
- Input Power
- 5 VDC
Physical
- Environmental Resistance
- No
- Dimensions
- 53.9 x 28.7 x 22 mm
- Weight
- 25.1 g
